Customised Hydraulic Thrust Cylinder with Spherical Bearing Mounting
Documents & Certificates
This series of Hydraulic Thrust Cylinders is specially designed for pushing applications, featuring a robust construction suitable for a wide range of industrial and engineering tasks.
The cylinders can be fully customised to meet different requirements, including stroke, capacity, mounting type, and end connection.
Whether applied in bridge construction, civil engineering, machinery installation, or other special applications, they deliver efficient, safe, and reliable thrust solutions.
The cylinders can be fully customised to meet different requirements, including stroke, capacity, mounting type, and end connection.
Whether applied in bridge construction, civil engineering, machinery installation, or other special applications, they deliver efficient, safe, and reliable thrust solutions.
(Below table provides typical dimensions for reference. Custom specifications are available upon request.)
| Capacity (ton) | Outer Diameter (mm) | Rod End Hole Diameter (mm) | Rod End Thickness (mm) | Rod End Radius (mm) | Rod End Center Distance (mm) | Cylinder Length (mm) |
|---|---|---|---|---|---|---|
| 40 | 50 | 20 | 30 | 25 | 207 | 139 |
| 50 | 60 | 25 | 35 | 30 | 228 | 148 |
| 63 | 73 | 35 | 45 | 40 | 249 | 159 |
| 80 | 95 | 40 | 55 | 45 | 297 | 187 |
| 100 | 115 | 45 | 60 | 55 | 364 | 220 |
| 125 | 145 | 50 | 80 | 70 | 400 | 236 |
| 140 | 160 | 60 | 85 | 80 | 452 | 262 |
| 150 | 170 | 70 | 95 | 85 | 507 | 297 |
| 160 | 185 | 80 | 100 | 95 | 535 | 305 |
| 180 | 205 | 80 | 110 | 105 | 580 | 330 |
| 200 | 230 | 90 | 120 | 115 | 625 | 355 |
| 230 | 273 | 100 | 150 | 135 | 625 | 355 |
| 250 | 295 | 110 | 150 | 145 | 713 | 403 |
| 300 | 355 | 120 | 180 | 175 | 828 | 438 |
| 350 | 405 | 150 | 220 | 200 | 1650 | 1050 |
| 400 | 457 | 200 | 220 | 250 | 3100 | 2480 |
