Aluminum Double Acting Cylinder
|
Model
|
Cylinder
Capacity
(ton)
|
Stroke
(mm)
|
Collap.Height(mm) |
Outside
Dia.
(mm)
|
Cylinder
Bore Dia.
(mm)
|
Weight
(kg)
|
| SAD-502 |
50
|
50
|
201 | 145 |
95
|
11.1
|
| SAD-504 |
50
|
100 | 251 | 145 |
95
|
12.7
|
| SAD-506 |
50
|
150
|
301 | 145 |
95
|
14.3
|
| SAD-1004 | 100 | 100 | 301 | 185 | 135 | 19.3 |
| SAD-1006 | 100 | 150 | 351 | 185 | 135 | 24.2 |
| SAD-1008 | 100 | 200 | 401 | 185 | 135 | 25.1 |
| SAD-1506 | 150 | 150 | 348 | 230 | 170 | 33.3 |
