Products:

  • Single strand pusher (Rear Grip)

    Model Capacity (ton) Stroke (mm) Body (mm) Hole (mm) Overall Size (mm) Piston Area A(c㎡) JKD-10 10 150 70 17 447 17.6 JKD-20 20 160 90 17 485 31.4 JKD-308 30 200 105 17 535 40.4

  • Hydraulic Mechanical Steel Strand Pusher

    The pusher designed by idea of hydraulic system with low rotation rate and high torque features. The power was driven by motor which operate at a high pressure pump, then transmit through to hydraulic motors for the mechanical means. This device provides low and high speed. Operating speed from Low speed of 600RPM to high speed of 1100RPM The pusher is Capable of push over 100M at low speed and 160M in high speed. The fitting gauge showed pushing length obviously within operation. The machine is capability of adjusting and retracting the superabundant strand at low speed with ease. The strand frame produced by our company is made of most practical iron material. Assembling easily, operation without crane, practical to use, low budget and high work efficiency. Power used: 220v,3∮,60HZ,30HP。 Dimension: 145/cm(H),150/cm(W),160/cm(L) Plus other standards for your option, 15HP and 7.5HP. Model SSP-7.5 SSP-15 SSP-30 Max threading capacity 13~16mm 13~16mm 13~16mm Max length threading capacity Above 60M Above 100M Above 160M Speed 39M~230M/min 80M~160M/min 80M~160M/min Horsepower(HP) 7.5HP 15HP 30HP Electricity 220V 50/60HZ 220V 50/60HZ 220V 50/60HZ Volume 750x410x550mm 1220x1280x1000mm 1500x1400x1400mm Weight 175kg 480kg 800kg

  • Single-strand pusher (Front Grip)

    Model Capacity (ton) Stroke (mm) Body (mm) Hold (mm) Overall Size (mm) Piston Area A(c㎡) JAD-308 30 200 115 25 496 47 JAD-3030 30 800 115 25 1110 47

  • Jacks - Power Team

    SIDEWINDER JACKS Designed compactly to fit in your palm, the Power Team sidewinder jack operates horizontally or vertically for easier use in confined spaces. Retracted height of just 2 9/16" (63,5 mm) for the smallest jack and 5 1/8" (130,2 mm) for the 20 ton, allows for optimal mobility and use-ability in narrowly spaced situations. The sidewinder jack features handles to function in line with the base of the jack for easier use in confined spaces. The versatile sidewinder jack can be used as for lifting, or for spreading applications. Use it vertically or horizontally in a limited clearance situation. Meets ASME B30.1 standard.View Catalog - Sidewinder Jacks - US ‖ UK ‖ DE ‖ ES ‖ FR LOW PROFILE BOTTLE JACKS The Power Team low profile bottle jacks are specifically designed and fabricated to fit a range of lower clearance jobs. All the quality, features and lifting capacity of the standard jacks offering 12-ton and 20-ton model variants. All Power Team low profile bottle jacks feature screw extensions for added versatility. All jacks meet ASME B30.1 standards PowerThon™ Lifetime Warranty. All jacks operate both vertically and horizontally for use in a variety of lifting, pushing and spreading applications.View Catalog - Low Profile Bottle Jacks - US ‖ UK ‖ DE ‖ ES ‖ FR BOTTLE JACKS The Power Team Bottle Jack is intently constructed ot excel at industrial lifting and pushing applications. The 9110B, 9015B, 9022B and 9033B feature a beveled base which allows the jack to “follow” the load, reducing the chance of dangerous side-loading. Many jacks feature screw extensions some jacks can be used in the vertical, angled or horizontal positions. Serrated or contoured saddles help stabilize the load for a safer lift. All jacks meet ASME B30.1 standards and carry the PowerThon™ Lifetime Warranty. 110-ton jack features dual pumps for time-saving two-speed operation.View Catalog - Bottle Jacks - US ‖ UK ‖ DE ‖ ES ‖ FR TELESCOPING BOTTLE JACKS The Power Team telescoping bottle jacks offer extended lifting capability. Telescoping jacks are designed to accommodate all of the quality features and capabilities of the standard bottle jack line. The super-long stroke of these jacks saves time and effort by eliminating the need to lift, crib, lift, etc. In most applications, the user can place the jack once and complete the lift. The taller 9006X, 9011X and 9013X all feature a unique beveled base that allows the jack to “follow” the load laterally as it is raised, greatly reducing side-loading of the piston. Meets ASME B30.1 standard.View Catalog - Telescoping Bottle Jacks - US ‖ UK ‖ DE ‖ ES ‖ FR ECONOMY TOE JACKS The Power Team bottle jack-style toe jacks are loaded with many of the same features as our standard bottle jacks, but the toe-lift feature and swiveling pump handle socket make them ideal for machinery lifting and positioning. An internal pressure relief provides added safety by limiting the jack's lifting capability to the capacity of the toe. Spring return is an added feature on the larger jacks. Swiveling pump handle assembly available on the 5 and 10-ton models. The swiveling jack assembly allows you to access and pump the unit from numerous positions.  All jacks meet ASME B30.1 standards and carry the Power Team PowerThon™ Lifetime Warranty.View Catalog - Economy Toe Jacks - US ‖ UK ‖ DE ‖ ES ‖ FR HEAVY-DUTY TOE JACKS Heavy-duty low height industrial lifting and pushing applications. With lifting points on the toe and on the top, these extremely rugged jacks are ideal for machine lifting, rigging, lift truck service and much more.Choose from 5.5 ton, 11 ton, or the 27.5 ton lifting capacity. All jacks operated both vertically and horizontally. Base, toe and pumping assembly swivel independently, allowing the jack to work in confined areas. High strength piston and pump linkage for long life. Lever Bar included on all models. All jacks meet ASME B30.1 standards and carry the Power Team PowerThon™ Lifetime Warranty.View Catalog - Heavy-Duty Toe Jacks - US ‖ UK ‖ DE ‖ ES ‖ FR RJ SERIES Portable Railroad EditionHeavy-Duty Self-Contained Industrial Lifting Jack for Rail maintenance.Wide base cylinder design for stability.Double-acting cylinder with locking collar.The bottom of the cylinder is a bolted joint, using the base plate as part of the cylinder. This will allow for service of even the oldest or most abused jacks.Cribbing storage rack location is such that it allows easy access during cribbing placement and removal.Jack has a 20 ft. remote pendant for user safety and control.Easy to maneuver, large tires and small footprint make it easy to get into tight spaces.Adjustable handle, allows the user to easily to position the jack under loads.View Catalog - RJ Series - US ‖ UK ‖ DE ‖ ES ‖ FR JE/JA SERIES Portable and compact, ideal for locomotive/rail car, mining and heavy equipment maintenance.Modular design allows you to change lifting modules to suit your tonnage or height requirements.Select the collapsed height to fit your most frequent application and add jacking modules to suit your needs.Exclusive load control system provides positive, chatter-free control when lowering the load.Remote operation for maximum operator safety and control, motor or/an valve options.Easy to maneuver with large tires and small “footprint” make it easy to scoot into the tightest quarters.Adjustable, heavy-duty handle makes this jack easy to move, position under vehicles.Shielded and sheltered hydraulic lines for safer, longer, trouble-free service.View Catalog - JE/JA Series - US ‖ UK ‖ DE ‖ ES ‖ FR INFLATABLE JACKS The non-skid space-age reinforced Power Team inflatable jack is perfect for a number of applications. Uninflated jacks are less than 1" (25,4 mm) thick, making lifting tasks in small spaces seem routine. Constructed of non-conducting, high-quality rubber material with multi-layer aramid fiber reinforcement, samples of the inflatable jacks are pressure tested to 20 bar and cycle tested (10,000 inflate / deflate cycles at 8 bar for 10,000 inflate / deflate cycles). The controller, shut-off and air hoses are all equipped with an industrial interchange style quick disconnect air coupler. Female half coupler bodies have a locking collar to help the operator avoid accidentally disconnecting the jack while under load. The top and bottom surface of the jack has a skid-resistant, interlocking pattern to assist in alignment of two jacks being used together. Single jack controller with "dead man" control (part number 350090) can be used individually or in multiples to regulate the number of jacks desired. Heavy attachment handles are provided on the two largest jacks for attachment of a rope or hook to help in positioning the jack. Inflation hose system is color-coded (red and yellow) for easy recognition when using more than one jack. The jacks can be used at ambient temperatures of -20°c (-4°f) to + 50°c (+ 122°f).Inspect before and after each use. Replace if any signs of degradation or wear that may affect safety or performance. Keep the product clean. Store properly.View Catalog - Inflatable Jacks - US ‖ UK ‖ DE ‖ ES ‖ FR MAINTENANCE SETS Turnkey, extremely versatile mechanics maintenance kit fits many applications.Matched hydraulic system components, adapters and hydraulic spreader, contained in a rugged carrying and storage case.Portable sets are ideal for pushing, pulling, lifting, straightening, or clamping at remote job sites.Cylinders in set are rated at 10 tons at 10,000 psi. Set components are designed for full rated capacity of cylinders.Set IM10H/IM10L includes hand operated pump. Set IM10E includes the Quarter Horse® electrically driven portable power unit.View Catalog - Maintenance Sets - US ‖ UK ‖ DE ‖ ES ‖ FR SK SERIES Versatile 10 & 25 Ton Start-up kit covers a range of lifting, shifting, and positioning needs.  Broad range of cylinder types and strokes to fit many applications.  SK10TE & SK25TE kits are CE Compliant.View Catalog - Start-Up Kits - US ‖ UK ‖ ES ‖ FR POST TENSIONING JACKS The Power Team post-tensioning jacks are Monostrand stressing jacks suited for work on slab-on-grade where dirt, heat and high volume use take their toll. Power Team post-tensioning jacks are of the most durable in the industry. Designed specifically to withstand high heat and wear. Available in single or double-acting models. Standard single-acting units have a 10" (254 mm) stroke. Other stroke lengths are available on special order. Dead-end seaters for production work and fieldwork available on special order. (part #400120) 3" (76,2 mm) detachable seater nose assembly easily replaced with optional 6" (152,4 mm) nose assembly. The jack of choice for highrise and elevated work, due to fast return time and lightweight. All hydraulic fluid controls are internal; more efficient and safer operation during tensioning and retraction. Standard double-acting units have an 8 1/2" (216 mm) stroke; others available on special order. Specially designed power team control valves are available for post-tensioning jacks.View Catalog - Post Tensioning Jacks - US ‖ UK ‖ DE ‖ ES ‖ FR

  • Cylinders - Power Team

    C SERIES Single-Acting, Spring-Return high quality, general purpose cylinder used for lifting and pressing. Designed to utilize aluminum bronze bearings to significantly reduce wear. Piston return speed and spring life are bolstered by Maximum sized springs. Constructed for durability, using a Solid steel cylinder body for integrity. Chrome plated piston rod resists wear and corrosion adding to the cylinder’s life cycle. Intricately customizable through the wide range of accessories available to thread onto piston rod, collar, or onto cylinder base.View Catalog - C Series - US ‖ UK ‖ DE ‖ ES ‖ FR CPS/RPS Precision-matched cylinder and pump set for wide range of applications. Four styles of cylinders within the CPS/RPS Series with each set featuring single or two-speed hydraulic hand pumps. CPS/RPS Series cylinders vary in tonnages with long, medium or short stroke depending. Includes necessary fittings, couplers and 6-foot (1,8 m) hose. Gauge and gauge mounting adapter is recommended. View Brochure - CPS/RPS - US CBT SERIES Single Acting, Spring-Return, threaded piston rod end and base that is built to accommodate accessories and adapters. Threaded cylinder collars, piston rod ends, and internal base threads simplify mounting. A 9796 3/8" NPTF female half coupler is standard with each cylinder; oil port threads are 3/8" NPTF.View Catalog - CBT Series - US ‖ UK ‖ DE ‖ ES ‖ FR RP SERIES Single-Acting, Spring-Return. Designed for pulling and tensioning. Heavy duty compression spring provides long cycle life and rapid extension of piston. Spring automatically extends piston rod when pump pressure is released.View Catalog - RP Series - US ‖ UK ‖ DE ‖ ES ‖ FR RA SERIES Half the weight of equal capacity steel cylinders, the RA Series cylinder utilizes an aluminum body that resists sparking in hazardous circumstances. The aluminum piston rod and aluminum cylinder bore resist wear and corrosion.View Catalog - RA Series - US ‖ UK ‖ DE ‖ ES ‖ FR RLS SERIES Single-Acting, Spring-Return Power Team cylinder, Ideal for confined areas from 1 5/8" (266,7 mm) to 4" (542,9 mm) clearance. Cylinder body, piston and gland nut are each Power Team treated for corrosion and abrasion resistance. The RLS Series is designed with the standard domed piston rod (5-30 ton) or swivel cap (50- 150 ton) to minimize the effects of off center loading. A unique heavy-duty spring provides fast piston return. A 9796 3/8" NPTF female half coupler is standard with each cylinder (the RLS50 has a 3/8" coupler which is not angled). Oil ports are 3/8" NPTF. Couplers on all cylinders, except RLS50, are angled upward for extra clearance.View Catalog - RLS Series - US ‖ UK ‖ DE ‖ ES ‖ FR RSS SERIES Single-Acting and Double-Acting Spring-Return cylinder. The RSS Series cylinder is ideal for confined areas from 3 1/2" (88,9 mm) to 11 7/16" (290,2 mm) clearance. Power Tech plated piston rods and gland nuts resist scoring and corrosion. Heavy duty return spring of the RSS Series cylinder provides fast piston return & low collapsed height. Coupler on 10 thru 50 ton models is angled upward 5° for added clearance. The RSS Series cylinder features a grooved piston top to keep loads from sliding. Cylinders can be “dead-ended” at full capacity. Removable carrying handles on 100 ton and 250 ton models.View Catalog - RSS Series - US ‖ UK ‖ DE ‖ ES ‖ FR RH SERIES Double-Acting industrial cylinder, Ideal for the pulling and tensioning of cables, anchor bolts, forcing screws, etc. The RH Series cylinder features interchangeable piston head inserts to a range of versatility in application. 30, 60, 100 Ton Double-Acting RH Series cylinders feature threaded collar built-in safety feature to prevent over pressurization of the retract circuit. Intricately designed the plated piston rod resists wear due to superior packings to provide high cycle life without leakage. Corrosion-resistant standpipe has “Power Tech” resistant treatment. Each cylinder has 9796 3/8" NPTF female half couplers. The 60 ton thru 200 ton steel models are equipped with removable carrying handles.View Catalog - RH Series - US ‖ UK ‖ DE ‖ ES ‖ FR RT SERIES Single-Acting, Spring-Return and Double-Acting Power Team cylinder, ideal for pulling and pressing. A proven design; used throughout industry for over 45 years. The RT Series cylinders are compactly designed to withstand full “dead-end” loads. Basic cylinder head can be changed from a tapped hole to plain hole by simply changing insert. Pistons have “Power Tech” treatment for corrosion and abrasion resistance.View Catalog - RT Series - US ‖ UK ‖ DE ‖ ES ‖ FR RGG SERIES Single Acting load return hydraulic Power Team cylinder, featuring tonnages ranging from 55 – 200. The Power Team patented swivel cap provides concentrated load centering up to 5 degrees Sealing technology provides rod lubrication to reduce friction and wear in the RGG Series cylinder. Optimized piston gland design resists side loading conditions and an integrated robust retaining ring withstands full load end stop and conforms with ANSI B30.1 standards Power-Tech+ nitrided components to inhibit corrosion and provide expectational durability Base mounting holes standard on all models (they are not maintained to port location) One high flow 3/8” NPTF female half coupler and carry strap w/ eyelets are included.View Catalog - RGG Series - US ‖ UK ‖ ES ‖ FR RDG SERIES The RDG Series cylinder features double Acting, hydraulic return, and tonnages ranging from 55-200. Power Team patented swivel cap provides concentrated load centering up to 5 degrees. The RDG Series cylinders are designed with a robust retaining ring to withstand full load end stop and conforms with ANSI B30.1 standards Safety relief valve prevents over-pressurization of the retract circuit Sealing technology provides lubrication to reduce friction and wear Sealing technology provides lubrication to reduce friction and wear Power-Tech+ nitrided components to inhibit corrosion and provide expectational durability Optimized piston gland design resists side loading conditions Base mounting holes standard on all models (they are not maintained to port location) Two high flow 3/8” NPTF female half coupler and carry strap w/ eyelets are included.View Catalog - RDG Series - US ‖ UK ‖ ES ‖ FR RD SERIES Double-Acting, Hydraulic-Return industrial cylinder. Designed for high tonnage and built for a high cycle life. The RD Series cylinder is precisely constructed for bridge lifting, building reconstruction, shipyard, utility and mining equipment maintenance. Aluminum bronze overlay bearings provide long life and the signature chrome plated piston rod is intentionally plated for corrosion resistance. The RD Series load cap is removable to expose internal piston rod threads for pulling applications; threads withstand full tonnage. Grooved ring pattern in load cap helps guard against load slippage. Each cylinder has two 9796 3/8" NPTF female half couplers. Built-in safety relief valve prevents over-pressurization of the retract circuit. Features mounting holes and collar threads.View Catalog - RD Series - US ‖ UK ‖ DE ‖ ES ‖ FR R SERIES Single-Acting, Load Return cylinders. The R Series cylinders feature a visible indicator band alerts when stroke limit is reached.  Overflow port (weep hole) stroke limiter prevents piston from being overextended.  Optional swivel load caps reduce the effect of off-center loading tilts up to 5 degrees.  Radial grooves on the top of cap reduce load slippage.Double-Acting, Hydraulic Return cylinders.  These cylinders come standard with swivel caps to reduce the effects of off-center loading. Built-in safety relief valve prevents over-pressurization of the retraction circuit.  Each cylinders has two 9796 3/8" NPTF female half couplers.View Catalog - R Series - US ‖ UK ‖ DE ‖ ES ‖ FR RA_L SERIES Single-Acting, Spring Return, Aluminum cylinders. The RA_L Series cylinders feature a positive mechanical locking collar to support extended load holding. This cylinder is specialized to supports lifted load for extended periods of time by utilizing hydraulic pressure release. At half the weight of steel cylinders of comparable capacity, aluminum cylinders are ideal for portability.View Catalog - RA_L Series - US ‖ UK ‖ DE ‖ ES ‖ FR R_L SERIES Single-Acting, Load Return, Steel Cylinder. The R_L Series cylinders feature a positive mechanical locking collar to support extended load with hydraulic pressure released. Visible indicator band alerts when stroke limit is reached.  Overflow port ("weep hole") stroke limiter prevents piston from being overextended.View Catalog - R_L Series - US ‖ UK ‖ DE ‖ ES ‖ FR

  • Multi-Strand Hydraulic Stressing Jacks

    Manufactured by process : Based on a client’s requirements, we make an offer of a hydraulic product, giving its actual dimensions and loading capacity .The offer is discussed with the client to ensure that their requirements are satisfied (this is not necessary if the client provides drawings and specifications). Procurement of raw materials as per specifications of JIS G4105 SCM440. Boring the material (the raw material being solid). Rough machining to a +/- 2 ~ 4mm precision in dimensions, followed by heat treatment to re-adjust material characteristics. Heat treatment to machine workable range. The heat treatment increases the hardness and durability of the material, lengthening its service life. Welding the copper, which can be done in three ways : oxy-acetylene welding of copper, gas metal arc welding of copper (GMAW), and CO2 welding. Our factory uses oxy-acetylene welding of copper, which is the most expensive method , but yields the best results. Fine machining (boring, threading, lathe processes) Filling up the holes, grinding Electroplating the piston and inside of the cylinder (to increase the hardness of contact surfaces). Verify the serial numbers, then assemble the various parts (including sealing rings) Testing Product Features : Combining with variegated methodological and pre-stressed material. (Only need to change the accessories) Small size, high efficiency also easily for operated and moved.  Model   Stroke A  (mm)  Outside Dia B  (mm)  Hole C  (mm)  Retracted Ht D  (mm)  Piston Area  (A/c㎡) JKD-758           200                200          75                 520               117 JKD-1008           200                240          80                 570               174 JKD-2008           200                325         112                 570               322 JKD-30010           250                400         142                 625               550 JKD-40012           300                470         185                 625               689 JKD-50012           300                490         200                 700               800 JKD-7008           200                670         300                 765              1101 JKD-10008        200       740       300             640           1659  Note : Custom-made Jacks according to clients requirements for shape, size, capacity and loading.

  • Pumps - Power Team

    P SERIES The Power Team P-Series hand pumps come in a variety of configurations to meet the requirements of your application.  Along with various oil capacities and flow rates, you can choose from the following options:Singe-speed or Two-speedSingle-acting or double-actingSteel or Aluminum10,000 psi (700 bar) or 21,750 psi (1500 bar)View Catalog - P Series - US ‖ UK ‖ DE ‖ ES ‖ FR RPS SERIES Precision-matched cylinders and pump set for wide range of applications.Four styles of cylinders to choose from.Sets feature single or two-speed hydraulic hand pumps.Cylinders of various tonnages with long, medium or short stroke.Includes necessary fittings, couplers and six foot hoses.View Catalog - RPS Series - US ‖ UK ‖ DE ‖ ES ‖ FR PA6 SERIES Compact design ensures that the Power Team PA6 series pump is lightweight and portable. The PA6 series consists of single-speed pumps designed to drive single-acting cylinders. The power unit of choice for major manufacturers of auto body, frame straighteners and other equipment. Operates at 40-100 psi (3-8 bar) shop air pressure at the pump, dBA 85 at 10,000 psi (700 bar). Serviceable pump motor is not a “throwaway”, providing economical repair. Permanently vented reservoir cap. Internal relief valve protects circuit components, air inlet filter protects motor.View Catalog - PA6 Series - US ‖ UK ‖ DE ‖ ES ‖ FR PA6D SERIES Compact, lightweight and portable the Power Team PA6D series pumps are single-speed pumps for driving double-acting cylinders. The PA6D series pumps operate at 40-100 psi (3-8 bar) shop air pressure at the pump. Designed with longevity in-mind the PA6D series feature internal relief valve protects circuit components, air inlet filter protects motor. Serviceable pump motor is not a “throw away”, providing economical repair. Permanently vented reservoir cap. dBA 85 at 10,000 psi (700 bar) for all PA6 pump.View Catalog - PA6D Series - US ‖ UK ‖ DE ‖ ES ‖ FR PA9 SERIES Ideal for powering single-acting cylinders and portable hydraulic tools, the Power Team PA9 series pumps are easier to operate than a hand pump, designed for efficiency. Built to be economical in service; the PA9 series is not a “throwaway” unit. Unique bladder design for all-position operation and storage. Operates on 40-120 psi (3-8 bar) shop air, at 20 cfm (570 l). Hard-coat anodized aluminum housing. Oil filler with integral safety relief minimizes chance of damage to reservoir bladder if overfilling occurs.View Catalog - PA9 Series - US ‖ UK ‖ DE ‖ ES ‖ FR PA60 SERIES A two-speed pump, the Power Team PA60 series pumps are designed for rapid oil delivery at low pressure to quickly advance cylinder or tool. Equipped with air pressure regulator, air filter and lubricator. Serviceable air motor for economical repair. Internal relief valve protects circuit components. Permanently vented reservoir cap.View Catalog - PA60 Series - US ‖ UK ‖ DE ‖ ES ‖ FR PA50 SERIES Focused on single-speed and low pressure the Power Team PA50 series pump outputs 3,200 PSI / 220 BAR, fitting serviceable requirements for air motor for economical repair. Integrated air inlet filter protects motor. The PA50 series also features a filter in outlet port protects against contaminated systems Assorted reservoirs to suit your application's requirements.View Catalog - PA50 Series - US ‖ UK ‖ DE ‖ ES ‖ FR PA17 SERIES Rotary-Style Air Motor.  Use where air is the preferred source of energy.  Two-speed operation for high speed cylinder advance.  Durable two gallon thermoplastic reservoir. (Metal reservoir conversion kits are available.)  Air motor capable of starting under full load.View Catalog - PA17 Series - US ‖ UK ‖ DE ‖ ES ‖ FR PA46/PA55 Rotary-Style Air Motor.  Use where air is the preferred source of energy.  3 hp motor starting under full load.  Two-speed operation for rapid cylinder advance.  Models available with full remote control over advance and return, except PA554.  Tandem center valve holds the load when pump is shut-off.View Catalog - PA45/PA55 Series - US ‖ UK ‖ DE ‖ ES ‖ FR PUA/PMA SERIES The Power Team PUA/PMA series pumps provide infinitely variable capacity and discharge pressure. Suitable for continuous start/stop applications Pumps oil, water, and other fluids Stainless steel pump and check valves standard Maintains pressure with minimal power consumption (Non-load holding) Usable in hazardous areas: per ATEX II, CAT. 2 GDcT5 Quiet operation Can operate on gases other than air Simple to install and maintain Compact, rugged design Only 15 psi (1 bar) air pressure required to start pump Requires flooded inlet Vertical mount.View Catalog - PUA/PMA Series - US ‖ UK ‖ DE ‖ ES ‖ FR PB SERIES Compact, Portable, Cordless Hydraulic Pump for MRO Applications.  Compact, Li-ion 18VDC, 9.0 Ah battery-powered pump provides extended run-time.  Two-stage, high-pressure hydraulic pump offers quick tool advancement in the first stage.  Extremely compact, lightweight with an ergonomic handle grip and transport strap to ease portability.  Self-contained, rubber bladder reservoir allows pump usage in most positions with an impressive capacity of 70 cu. in. usable.  Quiet, smooth-running, serviceable brushed 18VDC motor.  High-impact, fiberglass reinforced shroud protects your investment in the most demanding and harsh applications.  Interchangeable valve configuration accommodates a vast array of applications.  CSA rated for intermittent duty, CE compliant.View Catalog - PB Series - US ‖ UK ‖ DE ‖ ES ‖ FRView Catalog - Maintenance Sets - US PE10 SERIES The 10 series Power Team hydraulic pumps are designed to have a maximum of 690 bar (10,000 psi) at a flow rate of 164 cc/min (10 cu. in/min). All Power Team pumps come fully assembled, and each with the ability to be valved for either single- or double acting cylinders. Designed to be compact can easily mobile, the power team 10 series includes a portable power source is included for hydraulic cylinders, and tools. The permanent magnet motor is strategically constructed to easily start under load, even with reduced voltage conditions. Battery-operated models have 8 foot (2,4 m) power cord with alligator clips to connect to any 12 volt battery, optional rechargeable battery pack with shoulder strap are alternatives for maximum portability. The Power Team 10 series pump typically delivers 15 minutes of continuous operation at 10,000 psi (700 bar) on a single battery. Built to withstand High-impact, shielded with a flame retardant construction.View Catalog - PE10 Series - US ‖ UK ‖ DE ‖ ES ‖ FR PE17 SERIES The Power Team 17 series pump is delibertly designed for maintenance and construction applications up to 55 Ton. For use with single-acting or double-acting cylinders at operating pressures to 10,000 psi (700 bar). For intermittent duty; starts under full load. Equipped with 1⁄2 hp (0,37 kW), 3,450 rpm, single-phase, thermal protected induction motor; 10 ft. remote control cord (PE172S has 25 ft. (7,6 m) cord) Low amperage draw; small generators and low amperage circuits can be used as power source. Extremely quiet noise level (67-81 dBA).View Catalog - PE17 Series - US ‖ UK ‖ DE ‖ ES ‖ FR PE18 SERIES Vanguard Jr. + Power Team 18 series pumps provide two-speed high performance in a light-weight, compact package. Designed to provide a gauge port and metal reservoir on all pump models. Equipped with a 1⁄2 hp (0,37 kW), 115 volt, 60/50 Hz single phase motor that starts under load, even at reduced voltage. Low amperage draw permits use with smaller generators and low amperage circuits. All pumps have a 10 foot (3 m) remote control. CSA rated for intermittent duty. Noise level of 85-90 dBA. For operating hydraulic crimping, cutting or other tools: No. PE184C - Allows you to alternately operate a spring-return cutting and/or crimping tool without disconnecting either tool. Select a port connection with a manual 4-way valve, start the pump with a remote control hand switch and extend the connected tool. When the hand switch is switched to off, the pump stops and the automatic valve opens, allowing the tool to return. In the center (neutral) position, a manual control valve holds the tool in position at the time valve is shifted.View Catalog - PE18 Series - US ‖ UK ‖ DE ‖ ES ‖ FR PE21 SERIES The 21 series Power Team pump and RD5513 cylinder used in a special press that produces pharmaceutical-grade extracts for herbal medicines. Totally enclosed, fan cooled induction motor: 1 hp (0,75 kW), 1,725 rpm, 60 Hz, single phase. Designed intentional for thermal overload protection. Remote control, with 10 foot (3,1 m) cord is standard on pumps with solenoid valves. Manual valve pumps have “Stop”, “Start” and “Run/Off/Pulse” switches. Pump controls are moisture and dust resistant. Motor drip cover with carrying handles and lifting lug. Low noise level of 70 [email protected] 10,000 psi (700 bar). In the event of electrical interruption, pump shuts off and will not start up until operator presses the pump start button. 24 volt control circuits on units with remote controls provide additional user/operator safety.View Catalog - PE21 Series - US ‖ UK ‖ DE ‖ ES ‖ FR PED SERIES Ideal for running multiple tools or cylinders from one power unit. Recommended for cylinders up to 75 tons. Two-speed pumps have the same low pressure and high pressure flows from both valves. Flows and pressures of each pump are independent. Delivers 300 cu. in./min. of oil at 100 psi (4,8 liter/min of oil at 7 bar) and 25 cu. in./min. at 10,000 psi (0,4 liter/min at 700 bar) from each pump. 1 1/2 hp, 110/115 volt, 60 Hz (1,12 kW, 220 volt, 50 Hz) induction motor, 10 foot (3,1 meter) remote control and 5 gallon (19 liter) steel reservoir. Models available for operating single-acting or double-acting cylinders. Each power unit contains two separate pumps and two separate valves allowing operator to control multiple processes with one power unit. Both pumps on each power unit are equipped with an externally adjustable pressure relief valve. Not recommended for frequent starting and stopping.View Catalog - PED Series - US ‖ UK ‖ DE ‖ ES ‖ FR PE30 SERIES The Power Team 30 series pump is intently ideal for maintenance and construction applications.  Operating both single-acting or double-acting cylinders. A dynamically built, Integral roll cage protects the 30 series pump from many forms of damage. 1 hp (0,75 kW), single phase, permanent magnet motor. High performance to weight ratio. Starts under full load even when voltage is reduced to 50% of nominal rating. Quit operations: 82 dBA @ 10,000 psi (700 bar) and 87 dBA @ 0 psi (0 bar). CSA rated for intermittent duty. Remote controls and/or solenoid valves feature 24 volt controls.View Catalog - PE30 Series - US ‖ UK ‖ DE ‖ ES ‖ FR PE46 SERIES The Power Team 46 series is best suited for under the roof maintenance and production applications. Equipped with two-speed high-performance pump, for use with single- or double-acting cylinders at operating pressures to 10,000 psi (700 bar) the 46 series pump is versitile. With a 1 1⁄2 hp (1.12 kW), 3,450 (2,875) rpm single-phase, 60 (50) Hz thermal protected induction motor that starts under full load. Noise level of 77-81 dBA. All equipped with a 10 foot (3,1 m) remote control except PE462S which has a 25 foot (7,6 m) remote control. 24 volt control circuit on all units with remote control. CSA rated for intermittent duty.View Catalog - PE46 Series - US ‖ UK ‖ DE ‖ ES ‖ FR PE55 SERIES A powerful multifaceted pump, the Power Team 55 pump excels at multiple applications. From heavy construction to concrete stressing this pump series is designed for intensity. With low voltage starting possible,  the 50/60 Hz universal motor; draws 25 amps at full load, and can start at reduced voltage. CSA rated for intermittent duty. 10 foot (3,1 m) remote motor control (except PE552S which has a 25 foot (7,6 m) remote motor and valve control). True unloading valve achieves greater pump efficiency, allowing higher flows at maximum pressure. Reservoirs available in sizes up to 10 gallons (38 liter). Lightweight and portable. Best weight-to-performance ratio of all Power Team pumps. “Assemble to Order” System: There are times when a custom pump is required. Power Team’s “Assemble to Order” system allows you to choose from a wide range of pre-engineered, off-the shelf components to build a customized pump to fit specific requirements. By selecting standard components you get a “customized” pump without “customized” prices. All pumps come fully assembled, add oil and ready for work.View Catalog - PE55 Series - US ‖ UK ‖ DE ‖ ES ‖ FR PE60 SERIES A compact lightweight pump, the Power Team 60 series is designed for rugged applications and low voltage starting. Experiencing a long, trouble-free life in the most demanding work environments, the 60 series is durable.. Powered by 1 1⁄8 hp, 115 volt, 60/50 Hz (0,84 kW, 220 volt, 60/50 Hz) single phase motor. Starts under load, even at the reduced voltages at construction sites. Optional fan-driven external oil cooler includes rollover guard. Insulated carrying handle. Integral 4" (102 mm) diameter fluid-filled pressure gauge with steel bezel complies with ASME B40.1 Grade A. 0 to 10,000 psi (0 to 700 bar) pressure range in 100 psi (7 bar) increments. Sealed 3⁄4 gallon (4,34 liter (usable) reservoir. Reservoir drain port is standard. Standard oil level sight gauge for accurate oil level monitoring. External spin-on filter removes contaminants from circulating oil to maximize pump, valve and cylinder/tool life.View Catalog - PE60 Series - US ‖ UK ‖ DE ‖ ES ‖ FR PQ60 SERIES The Power Team PQ60 series pumps are designed specifically for heavy-duty, extended cycle operation. Integrating single- or double-acting cylinders the PQ60 series is versatile. Constructed for longevity by employing a metal shroud keeps dirt and moisture out of motor and electrical components. An electrical shut-down feature prevents unintentional restarting of motor following an electrical service interruption. Internal relief valve limits pressure to 10,000 psi (700 bar). External relief valve is adjustable from 1,000 to 10,000 psi (70 to 700 bar). The Power Team PQ60 pumps operate below maximum OSHA noise limitation (74-76 dBA). Start and operate under full load, even with voltage reduced by 10%.View Catalog - PQ60 Series - US ‖ UK ‖ DE ‖ ES ‖ FR PQ120 SERIES The Power Team 120 series pump is exactingly designed for heavy duty, extended cycle operation up to 400 Ton. Built in grit, the series 120 pump can start and operate under full load, even with voltage reduced 10%. An electrical shut-down feature prevents unintentional restarting of motor following an electrical service interruption. Internal relief valve limits pressure to 10,000 psi (700 bar) and an external relief valve is adjustable from 1,000 to 10,000 psi (70 to 700 bar). Pump prewired at factory with a 3 hp, 460 volt, 60 Hz (2,24 kW, 380 volt, 50 Hz), 3 Phase motor. Other electrical configurations are available. 24 volt control circuits on units with remote controls for added user/operator safety. 3 hp (2,24 kW) 3 phase motor with thermal overload protection. Motor starter and heater element supplied as standard equipment; with an intentionally designed metal shroud to keep dirt and moisture out of motor and electrical components. Pumps operate below maximum OSHA noise limitation.View Catalog - PQ120 Series - US ‖ UK ‖ DE ‖ ES ‖ FR PE400 SERIES With high tonnage double-acting cylinders, the Power Team 400 series offers both single or multiple cylinder applications. Two-speed high output pump delivers up to 5 gpm (16 liter/min) of oil, with a low noise level of 73-80 dBA. Integral electrical shut-down feature prevents unintentional restarting of motor following an electrical service interruption. Over-current protection prevents damage to motor as a result of overheating. “Stop” and “Start” control buttons are 24 volt. PE4004 has a 4-way/3-position manual valve. The PE4004S has a 4- way/3-position solenoid valve with a 24 volt remote hand switch. External pressure relief valve is adjustable from 1,500 to 10,000 psi (100 to 700 bar). Heavy duty 4" (50,8 mm) diameter casters assure easy maneuvering. 20 gallon (3,927 cu. in. usable) / 75,7 liter (62,8 liter usable) reservoir has a low oil level sight gauge. Powered by a dual voltage 10 hp (7,46 kW), 3 phase, 1,725 (1,437) rpm motor. 3 phase motor has all the electrical components necessary to operate the pump.The customer has no hidden charges when making purchase. Deliver 1,200 cu. in./min. (16 liter/min) of oil @ 200 psi (15 bar), 420 cu. in./min. (5,6 liter/min) of oil @ 10,000 psi (700 bar).View Catalog - PE400 Series - US ‖ UK ‖ DE ‖ ES ‖ FR MCS SERIES Power team synchronized lifting and lowering system, the MCS ( motion controller system ) series can be used in many hydraulic applications where load position is critical, requiring cylinder synchronization. Whether it is a bridge, a building or any kind of heavy load, with the SPX FLOW power team motion control system, lifting, lowering, pushing, pulling, tilting or positioning loads can be carried out automatically with a high degree of accuracy. The PLC-controlled system is a combination of digital actuation and digital control providing significant advantages such as time savings, repeatability, and extremely low internal stress in the object one is moving. The system also provides documentation for the movement performed.View Catalog - MCS Series - US ‖ UK ‖ DE ‖ ES ‖ FR PE-NUT SERIES Extremely durable yet lightweight and operable under low-line voltage conditions, the Power Team PE-NUT series pumps are constructed for challenging conditions. A 115V 5/8 hp (0,46 kW) universal electric motor (50/60 cycle), employing a two-stage pump for efficiency and designed for use with spring-returned remote tools. The PE-NUT series pumps also feature high-pressure safety relief valve, remote hand control with 10-foot (3,1 meter) cord, and a pressure matched quick-coupler supplied. The PE-NUT series uniquely utilizes intermittent duty, piston-type high-pressure pump supercharged by a low-pressure pump. CAUTION: DESIGNED FOR CRIMPING APPLICATION ONLY! This system should not be used for lifting.View Catalog - PE-NUT Series - US ‖ UK ‖ DE ‖ ES ‖ FR PG120 SERIES Two-stage pump for crimping applicationsPG1203-CP6 hp Briggs & Stratton engine.Manual control valve.High-pressure safety relief valve.Protective roll cage.For use with single acting tools.PG1203/4S-CP5.5 hp Honda OHV-type engine.Solenoid valve with remote hand control with 10’ cord.Two-stage pump for rapid advance.High-pressure safety relief valve.Protective roll cage.For use with either single or double-acting tools.View Catalog - PG120 Series - US ‖ UK ‖ DE ‖ ES ‖ FR PG30/PG55 SERIES Gasoline power ideal for remote locations.  A logical choice at work sites where electricity or compressed air are unavailable. For single or double-acting cylinders at operating pressures up to 10,000 psi.  All gasoline engine/hydraulic pumps feature Posi-Check® valve to guard against pressure loss when valve is shifted from “advance” to “hold.”PG303 and PG304 (Up to 75 Ton)Powered by a 4-cycle, 2 hp Honda engine giving it the lowest weight to horsepower ratio of all gasoline driven pumps.Has an aluminum reservoir with 375 cu. in. of usable oil.PG30 series pumps are equipped with roll cages to protect pump from damage.PG303 is for single-acting cylinders, has a 9520 valve with separate internal return line which allows oil from running pump to return to reservoir, independently of cylinder return oil, when valve is in “return” position.PG304 is for double-acting cylinders, has a 9506 4-way (tandem center) valve.PG553 and PG554 (Up to 150 Ton)6 hp Intek “Diamond Edge” 4-cycle, by Briggs & Stratton.5 gallon reservoir.PG553 has a 9520 3-way valve for single-acting cylinders.PG554 has a 9506 4-way valve for double-acting cylinders.Optional roll cage available.View Catalog - PG30/PG55 Series - US ‖ UK ‖ DE ‖ ES ‖ FR PG120/PG420 SERIES Two-speed high-performance pumps ideal for construction, structure moving and rigging applications.A logical choice at work sites where electricity or compressed air are unavailable. For single or double-acting cylinders at operating pressures to 10,000 psi.All gasoline engine/hydraulic pumps feature Posi-Check® valve to guard against pressure loss when valve is shifted from “advance” to “hold.”PG1200 Series pumps powered by a Honda 4-cycle, 5.5 hp engine with automatic decompression and electronic ignition. Deliver over 0.5 gallon (130 cu. in.) of oil per minute at 10,000 psi.A 5 gallon reservoir means adequate capacity for multi-cylinder  applications. Dual element air cleaner protects engine from dusty environments.Heavy-duty “roll cage” provides pick-up points for lifting.  Horizontal bars on PG1203, PG1204 and PG1204S protect unit, provide hand holds for carrying.Rubber anti-skid insulation on bottom of reservoir resists skidding and dampens vibration. PG1200M-4 and PG1200M-4D include a pump cart with 12” wheels.Adjustable external pressure regulator.CSA rated for intermittent duty.View Catalog - PG120/PG420 Series - US ‖ UK ‖ ES ‖ FR HB SERIES The Power Team HB series is purposefully constructed to convert low-pressure portable hydraulic pumps or on-board hydraulic systems, into high pressure power sources. HB series applications include utilities, railroads, construction, riggers and others. This product operates single or double-acting cylinders, jacks, and tools such as crimpers, spreaders, cable cutters, or tire tools. Version for use with double-acting torque wrenches available. May be used to operate two separate, single-acting tools (with integral valves) independently, without need for additional manifold. Control valve included. Other Power Team valves available as an option to suit your specific application, if needed; consult factory. Compact and rugged for use inside a utility vehicle aerial bucket or stowing in a vehicle. No reservoir level to maintain; uses low pressure system as oil supply. Has 3⁄8" NPTF ports; compatible with standard fittings for low and high pressure systems.View Catalog - HB Series - US ‖ UK ‖ DE ‖ ES ‖ FR INTENSFIERS Portable two-speed pump operated in any position (open or closed-center) providing pressures up to 10,000 psi for the operation of high-pressure tools.FeaturesDesigned to intensify low-pressure system to 4,000-10,000 psiTwo-speed pump for rapid ram advanceDesigned to operate with external hydraulic oil systemsAll position mounting operationDesign permits operation on open or closed-center systemDual output pressure port selector valves (DUP models)High-pressure safety relief valveCarrying handle for portabilityPressure matched quick-couplers supplied The 25 Series Boosters represent an innovative concept, providing pressures up to 10,000 psi for the operation of high-pressure tools.Oil from an external source, such as a bucket truck or tractor, is intensified to 10,000 psi maximum. Low pressure from the source is bypassed through the booster for rapid ram advance.These compact, lightweight boosters do not have reservoirs. The units can be operated in any position on either open- or closed-center (accumulator) hydraulic systems. ATO SERIES Order a "Custom Built" Hydraulic Pump“Assemble to Order” means you can choose a basic pump with gas, air or electric motor. Then select the proper valve, gauge, pressure control, motor control and reservoir. You get a two-stage pump that gives high oil volume for fast cylinder approach (and return with double-acting cylinders) in the first stage and high pressure in the second stage.1-1/8 HP Universal Motor.  These motors start under full load and are suitable for operation up to 5,000 or 10,000 psi. The motor is 1-1/8 hp, 12,000 rpm, 115 or 230VAC (specify), 50/60 cycle AC single-phase (25 amp draw at 115VAC). With proper valve they can be used with single or double-acting cylinders. NOTE: Remote control available.1-1/2 HP Jet Motor, Single & Three-Phase.  Feature low noise level, moderate speed for long service and are ideal for fixed applications. Motor is 1-1/2 hp, 3,450 rpm, 115 or 230VAC, 50 or 60 cycle (specify), AC single-phase with thermal overload switch. Can be used with single or double-acting cylinders and equipped with remote control. Also available in 230/460VAC, three-phase (specify).  NOTE: These do not start under full load unless valve is in “neutral” (requires open or tandem center valve) and are not recommended for frequent starting and stopping.3 HP Jet Motor, Three-Phase.  Gives low noise level and long life due to its moderate operating speed. Ideal for fixed installations. Consists of basic 10,000 psi pump, jet pump motor: 3 hp, 3,450 rpm, 230/460VAC, 60 or 50 cycle (specify). AC three-phase, with thermal overload switch. Equipped with internal and external relief valve. Will start under load.3 HP Air Motor.  This pump is ideal for use where electricity is unavailableor cannot be used. The 5,000 or 10,000 psi pump has a 3 hp air-driven motor at 3,000 rpm (optimum performance based on 80 psi air pressure and 50 cfm at the pump). You can drive single or double-acting cylinders with the correct valve.  NOTE: 80 psi air supply required to start under full load.Gasoline Engine.  This version is perfect when electricity and air areunavailable. It is capable of continuous operation at full pressure. Consists of basic 10,000 psi pump, 4-cycle Briggs & Stratton “Diamond Edge” gasoline engine, developing 6 hp. As with all these pumps, this unit can be valved for use with either single or double-acting cylinders.View Catalog - ATO Series - US ‖ UK ‖ DE ‖ ES ‖ FR

  • Shop Equipment - Power Team

    10 TON PRESSES H-FrameIdeal for small pressing jobs; repairing small motors, armatures, removing and installing gears, bearings, other press-fit parts.  Choices of power sources include: single-speed hand pump, electric/hydraulic or air/hydraulic.Bench press has 15.38" x 16" work area.Floor press bed height is adjustable from 5" to 41" with horizontal "daylight" of 21".View Catalog - 10 Ton Presses - US ‖ UK ‖ DE ‖ ES ‖ FR 25 TON PRESSES C Frame Open Throat® design makes loading and unloading of work easy.Bench mount requires less than 1.5 sq. feet (1.4 sq. meter) of space; on optional pedestal, only 4 sq. feet (4 sq. meter) of floor space is needed.Cylinder head adjusts to three convenient working positions, providing up to 20 1/4" (514 mm)of “daylight.”Can be bench mounted or on optional pedestal base.Hydraulic cylinder delivers a 6 1/4" (159 mm) stroke and is driven by a P59 two-speed hand pump.View Catalog - 25 Ton Presses - US ‖ UK ‖ DE ‖ ES ‖ FR 55 TON PRESSES H FrameFull off-center pressing at full rated capacity across width of upper frame without buckling or bending.Maximum “daylight” is 42" x 36" (1.067 x 914 mm), making positioning of even bulky work pieces easy.Height of press bed is easily adjusted with winch; friction brake prevents bed from dropping and handle from spinning upon release.Presses with single-acting cylinder offer choice of 2-speed hand operated, electric/hydraulic, or air/hydraulic pump. Models with double-acting cylinder have an electric/hydraulic pump.Press models equipped with remote control enable operator to view work from all sides with fingertip control of cylinder piston travel.View Catalog - 55 Ton Presses - US ‖ UK ‖ DE ‖ ES ‖ FR 80 TON PRESSES H FrameThe original, patented Roll-Bed® extends out for easy loading and unloading with a crane or other lifting device, supporting loads up to 3,000 lbs.Movable workhead glides easily side-to-side for full off-center load capacity across width of upper frame.“Daylight” is 50 1/2" x 60" (1.283 x 1.524 mm) for 80 and 100-ton models; 51 1/4" x 64" (1.302 x 1.625 mm) on 150 and 200-ton presses.Fast approach of double-acting, 13 1/8" (334 mm) stroke cylinder is provided by PQ1204S “Quiet” electric/hydraulic pump with remote control hand switch. Operator can view work from all sides with fingertip control of cylinder piston travel.Adjustable lower bed width – For secure balancing and centering of heavy jobs. Loosen adjusting bolts to adjust bed from 4" (102 mm) to more than 27" (686 mm). See dimension “H.”Movable workhead – For off-center pressing jobs, workhead moves on bearings across upper bolster. Presses can be used at full capacity, regardless of where workhead is placed.Lifting mechanism – Simply turn crank handle to raise or lower upper bolster. Screw mechanism raises or lowers both sides evenly (a heavy-duty 1/2" drill motor can replace handle for automatic adjustment). Four locking pins hold bolster in place for pressing.Optional heavy-duty straightening fixtures – Make straightening jobs easy and accurate to within .004" (0.1 mm)! Rollers are ball bearing mounted and handle raises or lowers for easy turning of the work.View Catalog - 80 Ton Presses - US ‖ UK ‖ DE ‖ ES ‖ FR 100 TON PRESSES H FrameCylinder workhead glides across upper frame on rollers, locks in place for off-center pressing jobs. May be used horizontally for special pressing applications with user supplied supportsPress bed is raised and lowered by winch which locks in place for insertion of bed retaining pins.  Upper bolster can be lowered 8" (203 mm) for convenient positioning on repetitive jobs.Generous "daylight" of 42" x 50" (1.067 x 1.270 mm) accommodates bulky work pieces, uprights are placed for easy side entry of bars or shafts for straightening or bendingChoice of single or double-acting cylinder. Hydraulic pump options include: 2-speed hand pump with large 2-gallon (7,6 liter) reservoir, PE172 electric/hydraulic pump or "PQ" series "Quiet" electric/hydraulic pump with low noise.View Catalog - 100 Ton Presses - US ‖ UK ‖ DE ‖ ES ‖ FR 150 TON PRESSES H FrameMay be used horizontally for special pressing applications with user-supplied supports.Workhead has wide horizontal travel; rugged press frame withstands load of rated capacity across full width of frame.Winch mechanism provides easy positioning of press bed, locks in place for insertion of retaining pins.Upper bolster can be lowered 11" (279 mm) for convenient positioning on repetitive jobs.Uprights are placed for easy side entry of bars or shafts for straightening or bending.Fast cylinder approach is provided by PQ1204S “Quiet” electric/hydraulic pump.Remote control hand switch, enabling operator to view work from all sides with fingertip control of cylinder piston travel.View Catalog - 150 Ton Presses - US ‖ UK ‖ DE ‖ ES ‖ FR 200 TON PRESSES H FrameThe original, patented Roll-Bed® design. Bed rolls out for easy loading and unloading with a crane or other lifting device, supporting loads up to 3,000 lbs.Movable workhead glides easily side-to-side for full off-center load capacity across width of upper frame.“Daylight” is 50 1/2" x 60" (1.283 x 1.524 mm) for 80 and 100-ton models; 51 1/4" x 64" (1.302 x 1.625 mm) on 150 and 200-ton presses.Fast approach of double-acting, 13 1/8" (334 mm) stroke cylinder is provided by PQ1204S “Quiet” electric/hydraulic pump with remote control hand switch. Operator can view work from all sides with fingertip control of cylinder piston travel.Adjustable lower bed width – For secure balancing and centering of heavy jobs. Loosen adjusting bolts to adjust bed from 4" (102 mm) to more than 27" (686 mm). See dimension “H.”Movable workhead – For off-center pressing jobs, workhead moves on bearings across upper bolster. Presses can be used at full capacity, regardless of where workhead is placed.Lifting mechanism – Simply turn crank handle to raise or lower upper bolster. Screw mechanism raises or lowers both sides evenly (a heavy-duty 1/2" drill motor can replace handle for automatic adjustment). Four locking pins hold bolster in place for pressing.Optional heavy-duty straightening fixtures – Make straightening jobs easy and accurate to within .004" (0.1 mm)! Rollers are ball bearing mounted and handle raises or lowers for easy turning of the work.View Catalog - 200 Ton Presses - US ‖ UK ‖ DE ‖ ES ‖ FR FC SERIES Floor CranesAdjustable legs spread to clear obstacles (telescoping boom for extra reach)Rugged construction, reliable hydraulics.Boom collapses completely and legs fold for compact space-saving fold-away storage2-speed hydraulic hand pump provides fast boom travel and precise operator controlled descent.Roller bearing wheels and a steering dolly provide ease of mobility. Lifting chain is included.U.S. Patent No. 3,367,512View Catalog - FC Series - US ‖ UK ‖ DE ‖ ES ‖ FR

  • Extra-Thin Threaded Jack

    Manufactured by process : Use only area where limited space Mechanical Safety Lock Ring with thread to sustain the loading 5% Swivel design to withstand side loading High Strength metal alloy provides high durability Red visible marking to ensure within Piston Range Model Capacity (ton) Stroke A  mm Coll Height B  mm Ext Height C  mm Outs. Dia D  mm Cyl. Bore Dia E  mm Weight kg SCP-602 60 50 125 175 140 105.0 15 SCP-1002 100 50 137 187 140 136.7 26 SCP-1602 160 45 148 193 175 171.6 44 SCP-2002 200 45 155 200 220 190.7 57 SCP-2502 250 45 159 204 245 216.1 74 SCP-4002 400 45 178 223 275 266.9 134 SCP-5002 520 45 192 237 400 305.0 189  Note : Custom-made Jacks according to clients requirements for shape, size, capacity and loading.

  • Aluminum Double Acting Cylinder

    Model   Cylinder Capacity   (ton) Stroke   (mm) Collap.Height(mm) Outside Dia.  (mm) Cylinder  Bore Dia.  (mm)   Weight (kg) SAD-502 50 50 201 145 95 11.1 SAD-504 50 100 251 145 95 12.7 SAD-506 50 150 301 145 95 14.3 SAD-1004 100 100 301 185 135 19.3 SAD-1006 100 150 351 185 135 24.2 SAD-1008 100 200 401 185 135 25.1 SAD-1506 150 150 348 230 170 33.3

  • System Components - Power Team

    COUPLERS FeaturesCYLINDER AND HOSE COUPLERSDesigned for use up to 10,000 psi (700 bar) with hydraulic jacks, cylinders, etc. They are the threaded union type for interchanging cylinders in seconds. Each half is valved with a precision ball for a tight shutoff when disconnected. These couplers also permit the separation of cylinders or hose from pump when at 0 psi with minimal oil loss.NO-SPILL, PUSH-TO-CONNECT HYDRAULIC HOSE COUPLERSDesigned to permit high oil flow, the no-spill, push-to-connect couplers with locking collar and flush face design are for high pressure applications. The flush-face concept makes it easy to clean both coupler ends before connecting. Our unique push-to-connect, “dry-break” design eliminates oil spillage. The locking collar makes accidental disconnects a thing of the past. For 10,000 psi (700 bar) operation.HYDRAULIC COUPLER DUST CAPDust cap fits either male or female half couplers. View Catalog - Couplers - US ‖ UK ‖ DE ‖ ES ‖ FR FITTINGS 10,000 psi (700 bar) fittings for all applications.View Catalog - Fittings - US ‖ UK ‖ DE ‖ ES ‖ FR GAUGES FeaturesHeavy-Duty Hydraulic Pressure GaugesGauges feature an easily readable and highly visible, red Day-glo® needle.High strength steel bourdon tube ensures high cycle life.Stainless steel cases and lens locking rings.4" and 6" (101,6 mm and 152,4 mm) dry gauges can be filled with silicone (Kit #9046).Have 1/4" NPT connections.Gauges are calibrated and comply to ASME B40.1 Grade B. DG100 Digital Pressure GaugesAccurate to within 1%, Long-life pressure transducer.Pressure values are displayed on large red LEDs in 10 psi or bar increments. When power cable is connected to gauge, display will scroll all characters, performing a self-diagnostic routine."Peak" hold feature with reset toggle switch and "Peak On" indicator; Hi/Low set point feature with relay outputs for Hi/Low alarms and/or control signals.A slow flashing display indicates pressure below the low limit.  Fast blinking display alerts if limit is exceeded.Operating temperature of 0 to 140°F for the electronic display and -20 to 180°F for the transducer. 9042DG & 9042DG1500 Digital Pressure GaugesDigital gauge is easier to read and offers better accuracy than a conventional analog gauge.The laser welded stainless steel sensor & socket and the IP67 weatherproof rating make this product suitable for use in the most demanding of applications.Five pre-programmed engineering units allow technicians to read pressure in the unit of measure most applicable to the process.Includes automatic-off battery conservation, pressure tare, minimum pressure memory and maximum pressure.Agency Compliance / Approval: RoHS, CE, ASME B40.7, UL, cUL 61010-1. View Catalog - Gauges - US ‖ UK ‖ DE ‖ ES ‖ FR HOSES Features Power Team hoses are intended for use with 10,000 psi (700 bar) applications.  Hoses can be ordered in a variety of diameters and lengths.  Customers can choose between wire-braided, polyurethane and non-conductive hoses. View Catalog - Hoses - US ‖ UK ‖ DE ‖ ES ‖ FR HYDRAULIC FLUIDS FeaturesStandard Hydraulic OilFor dependable performance of all your hydraulic pumps and cylinders.Contains foam suppressant additives and has a high viscosity index.Flame-Out® 220 fire resistant hydraulic fluid*Contains anti-rust, anti-foam and antisludge additives.Provides fire resistant protection.(Note: Will burn if heat source is extreme enough. Will not, however, propagate the flame and is self-extinguishing when there is no ignition source.)Provides maximum lubrication and heat transfer.Offers a wider operating temperature range.No need to change seals in your Power Team equipment. Just drain the standard oil and replace it with Flame-Out® 220.Biodegradable Hydraulic FluidBiodegradable, non-toxic fluid withstands moderate to severe operating conditions; provides excellent protection against rust.Offers superior anti-wear properties, has excellent multi-metal compatibility. View Catalog - Hydraulic Fluids - US ‖ UK ‖ DE ‖ ES ‖ FR MANIFOLDS Pump mounted manifold enables the use of remote mounted accessories and valves.View Catalog - Manifolds - US ‖ UK ‖ DE ‖ ES ‖ FR COMPONENTS FeaturesPower Team offers the widest selection of pump component and accessories to meet your application needs.  Select from a variety of Motor Controls, Sub-plates, Air Filter / Regulator / Lubricator, Pressure Switch, Air Control Valves, Oil Cooler Kits, Reservoir Breather Kits, Casters, Fluid Level / Temp. Gauge, Foot Control Guard, Magnetic Strip, Seal Kits, Carts / Roll Cages, Reservoirs. View Catalog - Components - US VALVES FeaturesOperation with single-acting cylinder: Either oil port “A” or “B” must be plugged on valve. With port “B” plugged, solenoid is energized to position “A,” oil port “A” becomes pressurized. When solenoid is energized to position “B,” oil port “A” becomes the return port.Operation with multiple single-acting cylinders: A pressure line from one bank can be connected to oil port “A” and the other to oil port “B” on the valve. Sequence: When energized to position “A,” oil port “A” becomes pressurized and clamps the fixture connected to oil port “A”; oil port “B” becomes a “return” port for cylinder connected to oil port “B,” and retracts it. The opposite happens when solenoid “B” is energized.Operation with double-acting cylinder: Port “A” is connected to “advance” port of cylinder, oil port “B” connects to cylinder “return” port. Solenoid is energized to position “A,” oil port “A” becomes pressurized to extend cylinder piston. The opposite happens when solenoid “B” is energized. Valve does not hold in “retract” position.View Catalog - Valves - US ‖ UK ‖ DE ‖ ES ‖ FR

  • Single-Acting Jack

      Model Capacity (ton) Stroke(mm) Effective Area(cm3) Collap. Height   (mm) Out. Diam.  mm) Plngr. Diam.  (mm) Bore Diam.(mm) SGT-50 5  16 6.5  41  58  25.4  28.7 SGT-51 5  25 6.5  110  38  25.4  28.7  SGT-53  5  76 6.5  165  38  25.4  28.7  SGT-55  5  127 6.5  215  38  25.4  28.7  SGT-57  5  177 6.5  273  38  25.4  28.7  SGT-59  5  232 6.5 323  38  25.4  28.7  SGT-101  10  26 14.5  89  57  38.1  42.9  SGT-102 10  54  14.5  121  57  38.1  42.9  SGT-104  10  105  14.5  171  57  38.1  42.9  SGT-106  10  156  14.5  247  57  38.1  42.9  SGT-108  10  203  14.5  298  57  38.1  42.9  SGT-1010  10  257  14.5 349  57  38.1  42.9  SGT-1012  10  304  14.5  400  57  38.1  42.9  SGT-1014  10  356  14.5  450  57  38.1  42.9  SGT-151  15  25  20.3  124 69  41.4  50.8  SGT-152  15  51  20.3  149 69  41.4  50.8  SGT-154  15  101  20.3  200 69 41.4 50.8 SGT-156  15  152  20.3  271  69 41.4  50.8  SGT-158 15  203  20.3  322  69  41.4  50.8  SGT-1510 15  254  20.3  373  69  41.4  50.8  SGT-1512 15  305  20.3  423  69  41.4  50.8  SGT-1514  15  356  20.3  474  69  41.4  50.8  SGT-251  25  26  33.2  139  85  57.2  65  SGT-252  25  50  33.2  165  85  57.2  65  SGT-254  25  102  33.2  215  85  57.2  65  SGT-256  25  158  33.2  273  85  57.2  65  SGT-258  25  210  33.2  323  85  57.2  65  SGT-2510  25  261  33.2  374  85  57.2  65  SGT-2512  25  311  33.2  425  85  57.2  65  SGT-2514  25  362  33.2  476  85  57.2  65  SGT-308  30  209  42.1  387  101  57.2  73.2  SGT-502  50  51  71.2  176  127  79.5  95.2  SGT-504  50  101  71.2  227  127  79.5  95.2  SGT-506  50  159  71.2  282  127  79.5  95.2  SGT-5013  50  337  71.2  492  127  79.5  95.2  SGT-756  75  156  102.6  285  146  95.2  114.3  SGT-7513  75  333  102.6  492  146  95.2  114.3  SGT-1006  100  168  133.3  357  177  104.9  130.3  SGT-10010  100  260  133.3  449  177  104.9  130.3

  • Tools - Power Team

    C-CLAMP Used for clamping, pressing and bending. Ideal for welding and metal fabrication for fit-up of sheet or plate steel.FeaturesIn 5, 10, and 25 ton capacities. For use with Power Team general purpose single-acting series cylinders of comparable capacity.For clampling, pressing and bending. Ideal for welding and metal fabrication for fit-up of sheet or plate steel.Clamps withstand full rated capacity of the cylinders for which they are intended.To minimize the effects of off-center loading, the CC5, CC10, and CC25 should be used with the optional 350144 and 350145 swivel caps.View Catalog - C Clamps - US ‖ UK ‖ DE ‖ ES ‖ FR CRIMPERS FeaturesC12-Ton-BC-shaped head with 180º rotation for ease of accessibilityTrigger release handleOne of the most important products we have developed and marketed is the 12-Ton Series Tool. When we developed the 12-Ton Compression Tool more than 40 years ago, it became one of the first in a long line of technological breakthroughs in highpressure hydraulics.Compression Tools for U- or Shell-Type DiesTwo-Speed pump for rapid ram advance*High-strength fiberglass handlesC-shaped head with 360º rotation for ease of accessibility**Capactiy for all U- or shell-type diesTwist handle releaseHigh-Pressure safety relief valvePush-button system for ease of die insertion and removalWith carrying bagThe proof of the success of the HHT Series Tool is evident since competitors, both foreign and domestic, have copied features and designed their tools to imitate ours. We continue to set the standard of the industry with durable, long-lasting hand and remote tools. CUTTERS Features Compact, lightweight design for reaching tight placesHinged flip-top headEasy blade replacementPressure matched quick-coupler suppliesWith carrying caseThe 6-HCR Series Hydraulic Remote Cutting Tool is lightweight and compact, making it the perfect cutter for applications up to 3/4" (19,1 mm) diameter. The 13-HCR Series Remote Hydraulic Cutting Tool is designed for expanded cutting capabilities up to 2" (50,8 mm) diameter. The insert type cutter blades, top stationary blade and bottom advance blade can easily be replaced in the field with only a 1/4" (6,4 mm) blade screwdriver. NUT SPLITTERS SPX FLOW offers a selection of hydraulic nut splitters with cutter blades that are specifically designed to penetrate the nut to the precise point where cracks, without damaging the threads of the bolt. View Catalog - ENS Series - US ‖ UK ‖ CN ‖ DE ‖ ES ‖ FR ‖ IT ‖ TRView Catalog - HNS Series - US ‖ UK ‖ CN ‖ DE ‖ ES ‖ FR ‖ IT ‖ TR SPREADERS SPX FLOW Hydraulic spreaders can be used for a variety of tasks such as spreading concrete forms, breaking tire beads or flange work.  Multiple options allow you to choose what’s best for your needs.  View Catalog - FLS Series - US ‖ UK ‖ CN ‖ DE ‖ ES ‖ FR ‖ IT ‖ TRView Catalog - HFS Series - US ‖ UK ‖ CN ‖ DE ‖ ES ‖ FR ‖ IT ‖ TRView Catalog - HS Series - US ‖ UK ‖ CN ‖ DE ‖ ES ‖ FR ‖ IT ‖ TRView Catalog - Tire Removal - US ‖ UK ‖ DE ‖ ES ‖ FR HAND TOOLS Pliers, Wrenches, Service ToolsFeaturesPower Team offers the widest selection of tools and accessories to meet your application needs.  Select from a variety of Pliers: Retaining Rings, Horseshoe Lock Rings, Replacement Tips), Wrenches ( Pry Bars, Spanners, & Jimmy Bars), and Service Tools Accessories (Pipe Sealant, O-Ring Seal Picks, Thread Chaser, and Magnetic Pick-up Tool). View Catalog - Hand Tools - US ‖ UK ‖ DE ‖ ES ‖ FR HP SERIES Hydraulic PunchesFeaturesPunch smooth, precise holes in seconds. Much faster than drilling.Fully portable for construction, maintenance and service applications, or can be mounted on a workbench for production jobs.Has carrying handle for precise locating.Rugged, forged steel C-Frame for great strength and durability.Dual-action, spring-loaded stripper holds material during punching operation, strips material from punch on return. Scribe lines on stripper aid in locating the punch. View Catalog - HP Series - US ‖ UK ‖ DE ‖ ES ‖ FR HT SERIES Hydraulic Testers75 and 200 GPM In-Line Hydraulic TestersFeaturesAccurately measure oil flow, pressure and temperature on in-plant equipment, forklifts, machine tools and more.Temperature and flow readings are in Imperial and Metric and accurate to within ±2% of full scale.Dual pressure gauges for high and low pressure readings. Low pressure gauge is automatically shut-off and protected as pressure rises beyond its maximumreading.Automatic pressure compensating feature lets you increase flow without affecting pressure setting.Reverse flow through tester will not cause damage. A replaceable safety disc ruptures if pressure exceeds upper limit.Solid state voltage regulator eliminates errors caused by voltage change during testing.View Catalog - Testers - US ‖ UK ‖ DE ‖ ES ‖ FR

  • Double-Acting Jack

      Model Capacity (ton) Stroke(mm) Collap.Height(mm) Outside. Diam.  (mm) Bore Diam.(mm) DPC-1010 10 254 409 73 42.9 DPC-1012 10 305 457 73 42.9 DPC-308 30 209 387 101 73.2 DPC-3014 30  368  549  101  73.2 DPC-506 50  156  331  127  95.2 DPC-5013 50  334  509  127  95.2 DPC-5020  50  511  733  127  95.2 DPC-756  75  156  347  146  114.3 DPC-7513  75  333  525  146  114.3 DPC-1006  100  168  357  177  130.3 DPC-10013  100  333  524  177  130.3 DPC-10018  100  460  687  177 130.3 DPC-1502  150  57  196  203  158.8 DPC-1506  150  156  385  203  158.8 DPC-15013  150  333  564  203  158.8 DPC-15032 150  815  1116  203  158.8  DPC-2006  200  152  430  247  190.5  DPC-20013  200  330  608  247  190.5  DPC-20018  200 457  765  247  190.5  DPC-20024  200  610  917  247  190.5  DPC-20036  200  914  1222  247  190.5  DPC-20048  200  1219  1527  247  190.5  DPC-3006  300  153  485  311  241.3  DPC-30012  300  305  638  311  241.3  DPC-30018  300  457  790  311  241.3  DPC-30024  300  609  943  311  241.3  DPC-30036  300  915  1247  311  241.3  DPC-30048  300  1219  1552  311  241.3  DPC-4006  400  152  528  358  279.4  DPC-40012  400  305  690  358  279.4  DPC-40018  400  457  843  358  279.4  DPC-40024  400  610  995  358  279.4  DPC-40036  400  914  1300  358  279.4  DPC-40048  400  1219  1605  358  279.4  DPC-5006  500  153  577  379  304.8  DPC-50012  500  305  730  379  304.8  DPC-50018  500  457 882 379 304.8 DPC-50024  500  609  1032 379  304.8  DPC-50036  500  925  1339 379 304.8  DPC-50048  500  1219  1644  379  304.8

  • Pullers - Power Team

    MECHANICAL PULLERS Power Team Mechanical Pullers come in a variety of styles and configurations to meet the needs of your application.  Customers can choose between;Mechanical Jaw Pullers - offered in 2-Jaw, 3-Jaw and 2/3-Jaw styles and capacities up to 25T.Bi-directional Pullers – offer up to 30T of pushing or pulling force, depending on the setup.Specialty Puller Accessories – Do you have a unique application? Perhaps a Power Team Slide Hammer Puller, Bearing Cup Puller or Pulley Pullers are what you need! View Catalog - Mechanical Pullers - US ‖ UK ‖ DE ‖ ES ‖ FR HYDRAULIC PULLERS Power Team offers several varieties of hydraulic pullers to meet the needs of your application.  Choose one of the following types:Hydraulic Pullers – Offered in 2-Jaw, 3-Jaw and 2/3-Jaw configurations for up to 50T of force.Bi-Directional Pullers – Offer up to 50T of pushing or pulling force, depending on the setup.Push Pullers – Power Team Push Pullers are ideal for installing a wide variety of press-fit parts. View Catalog - Hydraulic Pullers - US ‖ UK ‖ DE ‖ ES ‖ FR POSI LOCK PULLERS With Power Team Posi Lock® , pulling bearings is a one-person operation. The T-handle and “Safety Cage®” control the jaws at all times. This means that the opening, closing, locking and aligning of the jaws is all done automatically by simply turning the T- handle.  The Posi Lock Pullers are offered in both mechanical and hydraulic versions.Mechanical - Mechanical pullers use a center bolt to provide force on the shaft enabling jaws to extract object in a controlled manner. Mechanical pullers are offered in capacities between 1T and 40T.Hydraulic - Hydraulic cylinder reacts off shaft enabling jaws to extract object in a controlled manner. Hydraulic pullers are offered in 5T to 50T capacities.Power Team Posi Lock Pullers are also offered in high tonnage varieties (100T & 200T) to provide the maximum extraction force in applications requiring high force removal of large gears, pulleys, wheels, sleeves and other press fit parts.View Catalog - Posi-Lock Pullers - US ‖ UK ‖ DE ‖ ES ‖ FR ENFORCERS The SPX FLOW Power Team Enforcer Pullers are offered in 55T and 100T versions and share the following features:Hydraulically-actuated jaws allow the cylinder to move in or out with a safe, secure grip on the work piece.The hydraulic lift system allows for easy, precise position of puller.A unique dual pump arrangement allows a low pressure pump to position, hold and open jaws. Then, the high pressure pump advances and retracts the pushing cylinder without releasing clamped jaws. View Catalog - Puller Enforcers - US ‖ UK ‖ DE ‖ ES ‖ FR RAIL BEARING PULLERS Power Team offers some unique pullers for railroad applications. With both sling and jack models available and two pumps to choose from, you can tailor the unit to match your needs. Each unit comes with a heavy-duty 100-ton hydraulic cylinder, 10,000 PSI pump with remote control solenoid valve, hydraulic pressure gauge, a pulling shoe and installing tube. View Catalog - Rail Bearing Pullers - US ‖ UK ‖ DE ‖ ES ‖ FR PULLER BLANKETS When using hydraulic or manual pullers for gears, bearings, wheels, or pulleys, SPX FLOW always recommends using Puller Blankets, along with appropriate Personal Protective Equipment (PPE). Our puller blankets are designed to contain leaking fluid, loose or broken parts and debris during the pulling or forcing operation. View Flyer - Puller Blankets - US PULLER ACCESSORIES Once you selected the appropriate puller for your application, make sure that you the necessary attachments and accessories to complete the job. Whether you need an adapter compatible with any number of threaded hole sizes, protecting the part to be pulled or for assisting the installation of a component; Power Team offers a variety of adapters to assist in the removal or installation of parts. View Catalog - Puller Accessories - US ‖ UK ‖ DE ‖ ES ‖ FR PULLER SETS Power Team offers several combinations of Puller Sets. Choose one of the following sets to add to your tool crib or maintenance tools.IPS Series - These “Master Puller Sets” are offered with mechanical pullers, or a combination of manual and hydraulic pullers. Each set contains pullers, a hand pump and several accessories.  Customers can choose pulling capacities of 10T, 17.5T, 30T and 50T.Posi Lock Puller Bundles – These turnkey puller sets offer 2-Jaw or 3-Jaw pullers, paired with a hand pump or electric pump, cylinder, hose and gauge. View Catalog - Puller Sets - US ‖ UK ‖ DE ‖ ES ‖ FR

  • Single Acting Hollow Jacks

    Model Cylinder Capacity (ton) Stroke (mm) Effective Area(cm2) Oil Capacity(cm3) Collap. Height  (mm) Out.Diam.  (mm) BoreDiam.  (mm) Hole Diam.  (mm) SHC-120 12 8 17.9 14 55 69 54.1 19.6 SHC-121 12 42 17.9 75 120 69 54.1 19.6 SHC-1211 12 42 17.9 75 120 69 54.1 19.6 SHC-123 12 76 17.9 136 184 69 54.1 19.6 SHC-202 20 49 30.7 150 162 98 73.1 26.9 SHC-206 20 155 30.7 476 306 98 73.1 26.9 SHC-302 30 64 46.6 298 178 114 88.9 33.3 SHC-306 30 155 46.6 722 330 114 88.9 33.3 SHC-603 60 75 61.8 705 250 160 130 54 SHC-1003 100 76 133 1011 254 212 165.1 79

  • Double Acting Hollow Jack

      Model Capacity (ton) Effective Area(cm3) Collap. Height   (mm) Out. Diam.  mm) Plngr. Diam.  (mm) Hole Diam.(mm) DHC-307 30 46.6 330 114 88.9 33.3 DHC-3010 30 46.6 431 114 88.9 33.3 DHC-603 60 94 250 160 130 54 DHC-606 60 94 323 159 123.9 53.8 DHC-6010 60 94 438 159 123.9 53.8 DHC-1001 100 133.0 165 212 165.1 79.2 DHC-1003 100 133.0 254 212 165.1 79.2 DHC-1006 100 133.0 342 212 165.1 79.2 DHC-10010 100 133.0 460 212 165.4 79.2 DHC-1104 110 165 260 235 140 80 DHC-1106 110 165 310 235 140 80 DHC-1108 110 165 360 235 140 80 DHC-11010 110 165 410 235 140 80 DHC-11012 110 165 460 235 140 80 DHC-1504 150 234.8 290 296 190 100 DHC-1506 150 234.8 340 296 190 100 DHC-1508 150 234.8 349 296 190 100 DHC-15010 150 234.8 440 296 190 100 DHC-15012 150 234.8 490 296 190 100 DHC-2004 200 304 300 322 220 110 DHC-2006 200 304 350 322 220 110 DHC-2008 200 304 400 322 220 110 DHC-20010 200 304 450 322 220 110 DHC-20012 200 304 500 322 220 110 DHC-2504 250 380.3 325 365 229 125 DHC-2506 250 380.3 375 365 229 125 DHC-2508 250 380.3 425 365 229 125 DHC-25010 250 380.3 475 365 229 125 DHC-25012 250 380.3 525 365 229 125 DHC-3006 300 465.5 420 404 280 150 DHC-3008 300 465.5 470 404 280 150 DHC-30010 300 465.5 520 404 280 150 DHC-30012 300 465.5 570 404 280 150 DHC-3506 350 519 425 455 318 175 DHC-3508 350 519 475 455 318 175 DHC-35010 350 519 525 455 318 175 DHC-35012 350 519 575 455 318 175 DHC-4006 400 602.4 430 457 320 182 DHC-4008 400 602.4 480 457 320 182 DHC-40010 400 602.4 530 457 320 182 DHC-40012 400 602.4 580 457 320 182 DHC-5006 500 718.7 500 508 343 195 DHC-5008 500 718.7 550 508 343 195 DHC-50010 500 718.7 600 508 343 195 DHC-50012 500 718.7 650 508 343 195 DHC-7006 700 1004 505 650 405 230 DHC-7008 700 1004 555 650 405 230 DHC-70010 700 1004 605 650 405 230 DHC-70012 700 1004 655 650 405 230 DHC-10006 1000 1539 540 750 520 310 DHC-10008 1000 1539 590 750 520 310 DHC-100010 1000 1539 640 750 520 310 DHC-100012 1000 1539 690 750 520 310 DHC-13008 1300 1935.2 705 870 585 355 DHC-130010 1300 1935.2 755 870 585 355 DHC-130010 1300 1935.2 805 870 585 355

  • Single Acting Hydraulic Screw Jacks

    Single-axis and double-axis jacks are designed to allow the user conveniently where space is limited. Screw mechanical force is used to allow jacks to sustain pressure. Durable and high-strength screw design. Lightweight design in favor of removal. Model Capacity (ton) Stroke (mm) Plate Area (mm) Height (mm) Weight (kg) JMC-100 100 150 300*300 450 118 JMC-150 150 150 300*300 500 146 JMC-200 200 150 350*350 560 200 JMC-250 250 150 400*400 580 230 JMC-300 300 150 400*400 580 265 JMC-350 350 150 400*400 600 322 Capacity: 100~500 TON Model Capacity (ton) Stroke (mm) Plate Area (mm) Height (mm) Weight (kg) JSC-30 30 100 200*200 300 25 JSC-60 60 100 250*250 350 40 JSC-100 100 150 295*295 450 81 JSC-150 150 150 295*295 500 115 JSC-200 200 150 345*345 500 151 JSC-250 250 150 345*345 500 161

  • Single Acting Flat Height Cylinder

    Model Cylinder Capacity   (ton) Stroke   (mm) Effective Area(cm2)   Collap. Height   (mm) Outside Dia.   (mm) Cylinder  Bore Dia.   (mm)   Weight(kg) SFJ-50 50 6 6.5 32 58x41 28.7 1.0 SFJ-100 10 12 14.5 43 85x55 42.9 1.4 SFJ-200 20 11 28.7 51 101x76 60.5 3.1 SFJ-300 30 13 42.1 58 117x95 73.2 4.5 SFJ-500 50 16 62.1 66 139x114 88.9 6.8 SFJ-750 75 16 102.6 79 165x139 114.3 11.3 SFJ-1000 100 16 126.7 85 177x152 127.0 14.5 SFJ-1500 150 16 198.1 100 215x190 158.8 26.3

  • Single-Acting Lock Nut Jack

    Model Cylinder Capacity   (ton) Stroke   (mm) Collap. Height   (mm) Outside Dia.   (mm) Cylinder  Bore Dia.   (mm) Piston Dia.   (mm) SLL-502 50 50 165 125 95 95 SLL-506 50 150 264 125 95 95 SLL-5010 50 250 364 125 95 95 SLL-5012 50 300 414 125 95 95 SLL-1002 100 50 187 165 130 130 SLL-1006 100 125 287 165 130 130 SLL-10010 100 254 387 165 130 130 SLL-10012 100 300 437 165 130 130 SLL-1502 150 50 209 205 159 159 SLL-1506 150 150 390 205 159 159 SLL-15010 150 250 409 205 159 159 SLL-15012 150 300 459 205 159 159 SLL-2002 200 50 243 235 184 184 SLL-2006 200 150 345 235 184 184 SLL-20012 200 300 493 235 184 184 SLL-2502 250 50 245 275 216 216 SLL-2506 250 150 349 275 216 216 SLL-25012 250 300 499 275 216 216 SLL-3002 300 50 295 310 241 241 SLL-3006 300 150 395 310 241 241 SLL-30012 300 300 545 310 241 241 SLL-4002 400 50 335 350 267 266 SLL-4006 400 150 435 350 267 266 SLL-40012 400 300 585 350 267 266 SLL-5002 500 50 375 400 305 305 SLL-5006 500 150 475 400 305 305 SLL-50012 500 300 625 400 305 305 SLL-6002 600 50 395 430 330 330 SLL-6006 600 150 495 430 330 330 SLL-60012 600 300 645 430 330 330 SLL-8002 800 50 455 505 387 387 SLL-8006 800 150 555 505 387 387 SLL-80012 800 300 705 505 387 387 SLL-10002 1000 50 495 560 432 432 SLL-10006 1000 150 595 560 432 432 SLL-100012 1000 300 745 560 432 432

  • Single Acting Low Height Cylinder

    Model Cylinder Capacity   (ton) Stroke   (mm) Effective Area(cm2)   Collap. Height   (mm) Outside Dia.   (mm) Cylinder  Bore Dia.   (mm)   Weight(kg) SLC-101 10 38 14.5 88 69 42.9 4.1 SLC-201 20 45 28.7 98 92 60.5 5.0 SLC-302 30 62 42.1 117 101 73.2 6.8 SLC-502 50 60 62.1 122 124 8.9 10.9 SLC-1002 100 57 126.7 141 165 127.0 22.7

  • Hand Pump

    1. High displacement of oil per stroke. 2. Built for rugged industrial / construction use. 3. External adjustable relief valve. 4. Two speed operation. 5. Ultra light weight and compact design. 6. Built in safety valve provides overload protection. 7. Alloy aluminum construction resists corrosion and stand up to harsh environments. 8. Output port 3/8” NPT. Pump Type Usable Oil Capacity (cm3) Model No. Pressure Rating Oil Displacement Per Stroke (cm3) Dimension (mm) Weight (kg) 1st Stage 2nd Stage 1st Stage 2nd Stage L B H Two Speed 700 PA800 14 700 14.9 3.1 350 140 150 3.3 Two Speed 1300 PA1300 14 700 14.9 3.1 510 140 150 4.3

  • Single Hollow Aluminum Cylinder

    Model Cylinder Capacity   (ton) Stroke   (mm) Effective Area (cm2) Collap. Height   (mm) Outside Dia.   (mm) Cylinder  Bore Dia.   (mm)   Weight(kg) SAH-202 20 50 32.7 188 100 75 5.2 SAH-206 20 150 32.7 315 100 75 7.1 SAH-302 30 50 51.1 208 130 95 8.0 SAH-306 30 150 51.1 333 130 95 11.2 SAH-604 60 100 92.5 362 180 135 20.3 SAH-606 60 150 92.5 412 180 135 22.9 SAH-1006 100 150 155.1 391 250 185 43.4

  • Aluminum Single Acting Lock Nut Cylinder

    Model Cylinder Capacity   (ton) Stroke   (mm) Effective Area (cm2) Collap. Height   (mm) Outside Dia.   (mm) Cylinder  Bore Dia.   (mm)   Weight(kg) SAL-502 50 50 70.9 236 130 95 9.3 SAL-504 50 100 70.9 286 130 95 10.6 SAL-506 50 150 70.9 336 130 95 11.9 SAL-1002 100 50 143.1 296 180 135 21.9 SAL-1004 100 100 143.1 346 180 135 24.2 SAL-1006 100 150 143.1 396 180 135 26.5 SAL-1502 150 50 227 323 230 170 32.2 SAL-1504 150 100 227 373 230 170 36.2 SAL-1506 150 150 227 423 230 170 40.2

  • Single Acting Aluminum Cylinder

    Model Cylinder Capacity   (ton) Stroke   (mm) Effective Area (cm2) Collap. Height   (mm) Outside Dia.   (mm) Cylinder  Bore Dia.   (mm)   Weight(kg) SAT-202 20 50 31.2 174 85 63 3.6 SAT-204 20 100 31.2 224 85 63 4.1 SAT-206 20 150 31.2 274 85 63 4.6 SAT-302 30 50 44.2 181 100 75 4.5 SAT-304 30 100 44.2 231 100 75 5.2 SAT-306 30 150 44.2 281 100 75 5.9 SAT-502 50 50 70.9 186 130 95 8.5 SAT-504 50 100 70.9 236 130 95 9.8 SAT-506 50 150 70.9 286 130 95 11.1 SAT-1004 100 100 143.1 271 180 135 19.6 SAT-1006 100 150 143.1 321 180 135 21.9 SAT-1008 100 200 143.1 371 180 135 24.2 SAT-1506 150 150 227 343 230 17.0 33.3

  • Double Acting High Tonnage Cylinder

    型號Capacity(ton)stroke(mm)Coll Height(mm)Outside Diam(mm)Bore Diam(mm)DCC-5025053916213099DCC-5045010021213099DCC-5065015026213099DCC-50850 200 312 130 99DCC-501050 250 362 130 99DCC-501250 300 412 130 99DCC-1002100 50 179165 130DCC-1004 100 100229165130DCC-1006 100 150 279 165130DCC-1008 100 200329 165130DCC-10010 100 250379 165 130DCC-10012 100 300 429 165130DCC-1502 150 50 196 205 159DCC-1504 150 100 246 205 159DCC-1506 150 150 296205 159DCC-1508150 200 346 205 159 DCC-15010150 250 396 205 159DCC-15012 150 300 446 205 159 DCC-2002 20050 212235 184 DCC-2006 200 150 312235 184 DCC-20012 200 300 462 235 184 DCC-2502 250 50 235 275 216 DCC-2506 250 150335 275 216 DCC-25012300 300 485 275 216 DCC-3002 300 50 322 310241 DCC-3006 300 150 422 310 241 DCC-30012 300 300 572 310 241 DCC-4002 400 50 374 350 267 DCC-4006 400 150 474 350 267 DCC-40012 400 300 624 350 267 DCC-5002 500 50 419 400 305 DCC-5006 500 150 519 400 305 DCC-50012 500 300 669 400 305 DCC-6002 600 50 429 430 330 DCC-6006 600 150 529 430 330 DCC-60012 600 300 679 430330 DCC-8002800 50484505387DCC-8006 800 150 584505 387 DCC-80012 800 300 734505387 DCC-10002 1000 50564560 432

  • Double Acting Lock Nut Cylinder

    ModelCapacity(ton)Stroke(mm)Coll Height(mm)Outside Diam(mm)Bore Diam(mm)DLL-5025050295155115DLL-50650150395155115DLL-501250300560155115DLL-1002100 50 300 195145DLL-1006100 150 400 195 145DLL-10012100 300 575 195 145DLL-10020 100 500 830 195 145DLL-1502 150 50 315 235 175DLL-1506 150 150415 235 175DLL-15012 150 300 600 235 175DLL-15020 150 500 845 235 175DLL-2002 200 50 325 270200DLL-2006 200150 425 270 200DLL-20012 200 300610 270 200DLL-20020 200 500 855 270 200DLL-2502250 50 335 295 220 DLL-2506 250 150 435295 220 DLL-25012 250 300 620 295 220 DLL-25020 250500 865 295 220 DLL-3002 300 50355330245 DLL-3006 300 150455330245 DLL-30012 300 300 640330245 DLL-30020 300 500880330 245 DLL-30020300 500880330 245 DLL-4002400 50380375 280DLL-4006400 150 480 375 280 DLL-40012 400 300 665 375 280 DLL-40020400 500900 375 280

Note : Custom-made products are according to clients requirements for shape, size, capacity and loading.
